LED Matrix
16*16 APA102C LED Matrix

Application:

1. DIY electronic production.
2. Advertising.

3. Display.

4. Subtitles

Email: inquiry@ipixelleds.com

Share to

8*8 APA102C LED Matrix

Product Parameter:

P/N LED Qty/pcs Size(mm)
Pixel VCC Power IC Lumen per LED(MCD) IP
S1616APA102 APA102 256leds L160*W160
256 DC5V 75W/pcs APPA102C R:500-650 G:370-530 B:12-165 IP20



Features:

1. Individually addressable RGB LEDs (16*16 LEDs).
2. 24-bit color control (8-bit PWM per channel); 16.8 million colors per pixel.
3. Additional color-independent brightness control (5-bit PWM); 32 brightness steps per pixel.
4. SPI control interface,5 V operating voltage.
5. Each LED Matrix draws approximately 8A at full brightness.
6. 160 mm width (16 LEDs) or 160 mm width (16LEDs) Pitch : P10.
7. Flexible,bendable IP20 rating,Black strip color.
8. Power/data connectors on both strip ends for easy chaining.



Connection:
