16*16 WS2812B LED Matrix

Application:

1. DIY electronic production.
2. Advertising.

3. Display.

4. Subtitles

Email: inquiry@ipixelleds.com

Share to

16*16 WS2812B LED Matrix

Product Parameter:

P/N LED Qty/pcs Size(mm)
Pixel VCC Power IC Lumen per pcs IP
S1616WS2812 5050 RGB 256leds L160*W160
256 DC5V 51W/pcs WS2811
R:102400 G:179200 B:48640 IP20



Features:
1. WS2812B flexible LED matrix-16x16 pixels.
2. It's very easy to add any letters while each individually control .
3. That’s 256 individually addressable LEDs on a 160mm x 160mm flexible panel.
4. You can set any animations.
5. These panels require a 5V low voltage input for power which needs to be able to source a good amount of current – up to 5A in most uses(15A required wen you set all LEDs in white color).
6. There are two 3-pin JST SM connectors and two pcs bare power cables.
7. Red :DC5V+, Yellow:COM-, Green:DAT, and Yellow GND.
8. When the full panel set as white color , the whole PCB getting very hot even if.
9. We used 2 ounce Copper.
10. You must supply power to each panel when  you links many pcs.
Note: pls pay attention to the matrix when you bending the flexible panel.
