Digital LED Bar
360 View DMX Vertical Tube

Application:

1. Night Club
2. KTV singing club
3. Dance floor
4. TV Show Back gound
5. Stage,Disco Club

6. Outdoor building,fridge

Email: inquiry@ipixelleds.com



Share to

360 View DMX Vertical Tube

Product Parameter:

P/N LED Qty/PCS
Size(mm) Pixel VCC Power Protocol Channel MCD per LED
IP
B4816V12-A 5050 RGB 96leds L1035*D30 16 DC12V 19/pcs DMX512 48Ch R800/G2100/B480 IP65



Features:

1.This DMX Control LED Tube designed by clear PC tube,

2.The whole tube had 16 Pixel which is 48ch DMX address,
3.48pcs supper bright Epistar SMD RGB LED (one side),
4.Both side 96pcs LED make it 360 viewing,
5.Each tube included 1pcs eye hook for installation,
6.Every dmx tube attached a  waterproof 5Pin connector (black color),
7.The length of connector 20cm,5Pin 20AWG copper wire in white PVC,
8.The tube didn't attach any T type (3 way) connectors for power injection it request to purchase seperately,
9.The diameter is tube is 30mm (we also offer 23mm diameter size),
10.Avaliable size : 50cm & 100 cm.



Connection:








YouTube's  Video
