Digital LED Bar
5050 Single Color LED Rigid Bar

Application:

1. Back lighting.
2. Signage board.
3. Cabinet.
4. Jewelry store.
5. Indoor lighting.

Email: inquiry@ipixelleds.com


Share to

5050 Single Color LED Rigid Bar

Product Parameter:

Available Color
Luminous Flux
CCT(Kelvin)&Dominant Wave Length
Beam Angle

Typical
Typical
White
1000±10%
9000~10000K
140
Daylight White
1000±10%
6500~7000K
140
Warm White
1000±10%
3000~3500K
140
Red 420
623~628nm
140
Blue 750
525~530nm
140
Green 300 455~465nm
140



Features:

1.This is a regular aluminum light bar with aluminum PCB,
2.Milky white & clear shell,
3.DC12V ,14W/m, we used 60pcs high brightness SMD 5050 LED,
4.Non-waterproof for indoor use only,
5.We also could offer the aluminum case and PCB bar seperately,
6.Customised length size available or any size based on 5cm unit (<3m),
7.each bar included 2pcs metal buckle and 2pcs metal screw,
8.the standard version is non-waterproof , white color use milky white lens ,other color or RGB it's Clear PC lens, both side output 2Pin bare wire,
9.when you light up the LED bar , the Aluminum case getting very hot 50--60 degree,it's normal temperture, just make sure the voltage on each side are the same 12V.
1


Connection:
