Digital LED Bar
DMX LED Tube-16 Pixel

Application:

1. Night Club
2. KTV singing club
3. Dance floor
4. TV Show Back gound
5. Stage,Disco Club

6. Outdoor building,fridge

Email: inquiry@ipixelleds.com



Share to

DMX LED Tube-16 Pixel

Product Parameter:

P/N Size/m Beam Angle
VCC Power Protocol Channel LED Qty/m

MCD per LED

IP
B4816V12 1000*50mm 140 deg DC12V 14W/M DMX512 48CH 3535 RGB 48leds R800/G2100/B480 IP65
B4808V24 1000*50mm
140 deg
DC24V 14W/M
DMX512
24CH 5050 RGB 48leds
R800/G2100/B480
IP65


Features:

1.This DMX Control LED Tube designed by Aluminum case with a Milky,
2.white PC lens on top of the profile, but we also offer clear lens,
3.The whole tube had 16/8 Pixel which is 48/24ch DMX address,
4.48pcs supper bright Epistar SMD RGB LED,
5.each tube included 2pcs Aluminum clips,but without screw the clip can not change the angle after install to the wall,
6.every dmx tube attached a pair of waterproof 5Pin connector output from backside of profile, you can hide it with the power wire,
7.the length of connector 20cm,5Pin 20AWG copper wire in white PVC,
8.the tube didn't attach any T type (3 way) connectors for power injection it request to purchase seperately and we recommend every 5M tube supply power.



Connection:




Youtube's  Video
