LED Module
WS2801 Square LED Module

Application:

1. Backlighting for Advertisement.
2. Signboard and Billboard.
3. Backlighting for Lighting box Sign.
4. Decorative lights for holiday.
5. Event, show, and exhibition.

Email: inquiry@ipixelleds.com

Share to

WS2801 Square LED Module

Product Parameter:

P/N

VCC

Power

LED Qty/pcs

Housing Body

IC

Lumen per
Module

IP

M-35502801

DC12V

0.96W/pcs

 5050 RGB 4leds

Metal case

WS2801

R20/G40/B17 lm

IP65



Features:
1.Control IC included, supporting numerous color-change effects.
2.Pcontrol by SD controller,Arduino,DMX512,Artnet.
3.Flexible PCB white color, 5V low voltage input.
4.Every 1 Leds linear separable, custom-length available.
5.Eco-green light, no UV, IR.
6.Extremely long lifespan & lower power consumption.
7.Iron case 'pixel ' contains 4 RGB LEDs and a controller chip soldered to a PCB.
8.The pixel is  'flooded' with epoxy to make it waterproof.
9.There are two ears with hole on each side for screw installation.

Connection:
