APA2020 RGB LED Strip
Release time:2016-12-16 14:00:59 | Browsing times:


       What is awesome meaning !!! APA2020 LED chip , Top mounted IC+RGB Chip LED RGB single point of control, 8 bit color set, you wouldn't believe the package size is 2*2mm regarding to the special thin application.Here are APA2020 LED chip's Specifications:


 RGB Single point of control

• 8Bit(256 level)color set
• 5Bit(32level)brightnessadjustment
• ICinput voltage 4.5v--7.5v
• 20mA,Contant current output
• Anti-Reflectionresin
• View angle : >=120 (min 50% brightness)
• High contrast


APA2020

Specifications

Luminous Intensity(lv)

Red: 300--500mcd Green: 500--850mcd Blue: 120--220 mcd

R/G/B@20mA,Ts=25℃;Tolerance ±10%

Wavelength

Red: 619--626nm Green: 520--535nm Blue: 465--475nm
R/G/B@20mA, Ts= 25℃; Tolerance ±10%

Applied voltage

DC5V
Power consumption
0.2W

View angle

140°

Refresh rate

400 cycle

       We developed this slim led strip,4mm width 30pcs APA2020,totally flexible but IP20 as the brightness quite high based on very thin PCB,it getting a little bit hot,make sure you will hold the strip on somewhere which could lose the heat,never use static white color each LED addressable but not cut-able the soldering pad on front side is Data and clock, back side of PCB DC5V &GND Each pcs stripe we soldering a JST SM 4 Pin male connector as input ,cable size 26AWG.
