Full Color LED Strip
Side emitting SK6812 RGB LED stripe

Application:

1. Hotels, restaurants, nights clubs.

2. Back lighting, edge lighting.

3. Advertising signs, brightening.

4. Dancefloor background.

Email: inquiry@ipixelleds.com

Share to

             Side emitting SK6812 RGB LED stripe

Product Parameter:

Product Number
Light Source
Beam Angle
LED Quantity
Size (mm)
Emitting Color
Operating Voltage
Power (W)
Control (IC)
Waterproof Rating
S60SK6812SIDEV5
SK6812SIDE
120°
60leds/pcs
L1000*W8mm
Full color
DC5V
9±0.5w/1m
SK6812
IP20/IP67
S90SK6812SIDEV5
SK6812SIDE
120°
90leds/pcs L1000*W8mm Full color
DC5V
13.5±1w/1m SK6812
IP20/IP67
S144SK6812SIDEV5
SK6812SIDE
120°
144leds/pcs L1000*W8mm   Full color DC5V
21.6±1w/1m
SK6812
IP20/IP67



Features:

based on the old type of  side view LED like 335 or 1206 and more ,there are only single color and RGB
this new SK6812 side emitting addressable LED comes out under the demand of edge lighting with limited
size for install  the strip
this skinny side lit LED strip we have 3 different version of LED quantity 60/90/144 per meter
but all the PCB wide are 8mm and we provide IP20 /IP67 two version, the waterproof type housing

by silicon tube with JST connectors
each single LED per section allow you cut each unit so you can get the length  wanted by your self
the standard length 1meter per reel



Outline Dimension:

                                               60 LEDs/m

                                               90 LEDs/m

                                                144 LEDs/m

                                                 side view
