LED Pixel Light
35mm 360 Degree Lighting LED Ball
Application:
1. Night club, restaurant
2. Amusement rides, park
3. Concert hall, dance floor

4. Shop, indoor decoration

5.Garden, street landscaping

Email: inquiry@ipixelleds.com
Share to

                          35mm 360 Degree Lighting LED Ball

Product Parameter

P/N Diameter Ø Ball Qty Control Luminance(MCD) View Angle Voltage Wattage/pcs IP Rate
P035002CB3SC 35mm 20PCS/String SPI /DMX512

R: 1.2 G: 3.1

 B: 0.26

360° DC12V 0.5 W(Max) IP65


Features:

- IP65-rated RGB pixel LED light source

- DMX and SPI two versions available
- pixel pitch in 20mm, each sphere is 35 mm diameter
- Full 360° viewing angle, no lighting shadow
- Maximum length is 4.1 meters (20 balls per string)
- Practically maintenance-free
- Black flexible cable between each sphere



LED Technology:

Each string contains 20pcs milky white LED balls with a diameter of 35 mm .

Each ball with 2pcs RGB LED chip. It needs to feed power after every 20pcs balls

The durable IP65 rated design ensures that each ball could work in outdoor environment
The temperature of working environment is limted in -30℃ + 45 .



Product Control:

This ball can be operated by DMX512 or TTL signal controller.
A DMX converter (512 turns into SPI) is necessary if controlled by DMX controller.
This converter can support 64pcs Balls (192 DMX channel) max.
A DMX address coder (YM-DMXDC) is required if the DMX controller doesn't have the function
of setting address. Otherwise the balls work with SPI signal.
Each ball contains 1 Pixel / 3 DMX channel



Compared:




Youtube's Video
