Home > LED Flex > One Color > High Efficiency 2835 single color LED strip 90LEDs/M DC24V

High Efficiency 2835 single color LED strip 90LEDs/M DC24V

Description

-Luminance efficiency upto200LM/W，high Ra.

-Use 2835 high brightness led，high purity goldline，SAN AN chip.
-90LEDs/M， 1+2OZ copper thickness FPC，10mmPCB width.
-Higher efficiency：Consumes less energy，saving electricity and reducing energy costs.

-Longer lifespan：Lasts significantly longer，reducing the need for frequent replacements.

Share to

Specification

Product Parameter

PN	S010090BC1LZ	Luminance efficiency
Voltage	DC24V	CCT	Ra80	Ra90
Power	5W/m	X Custom	☆ Standard
LED Type	SMD 2835	X2000K	X145lm/w	X130lm/w
LED Quantity	90LEDs/m	X2300K	X160lm/w	X145lm/w
Dimension	5000*10mm	X2500K	X180lm/w	X160lm/w
Cutting Length	100mm/9LEDs	X2700K	X200lm/w	X180lm/w
SDCM	<5, 3 step 1 bin	☆3000K	☆200lm/w	☆180lm/w
ERP 2019	B / C	X3500K	X200lm/w	X180lm/w
Beam Angle	120°	☆4000K	☆200lm/w	☆180lm/w
IP Rate	IP20/IP64/IP65/IP67	X5000K	X200lm/w	X180lm/w
O.T	-25℃ ~ 60℃	☆6500K	☆200lm/w	☆180lm/w
