Home > LED Flex > One Color > S Shape 6mm 2835 static color LED strip 60LEDs/m DC12V/DC24V

S Shape 6mm 2835 static color LED strip 60LEDs/m DC12V/DC24V

Description

S shape(zigzag) flex led strip with SMD2835 static color 60LEDs/m
1+2 OZ copper thickness FPC,6mm PCB width
The biggest advantage is the S shape, which can be bend at any angle
Only available in IP20 non-waterproof version
Standard 5m per roll, the length also can be customized

Share to

Specification

Product Parameter

PN	S006060BB1LZ(S)	S006060BC1LZ(S)
Voltage	DC12V	DC24V
LED Type	SMD 2835	SMD 2835
LED Quantity	60LEDs/m	60LEDs/m
CCT	3000K/4000K/6500K	3000K/4000K/6500K
Lumens	515lm/m	515lm/m
Dimension	5000*6mm	5000*6mm
PCB Color	White	White
Power	4.8W/m	4.8W/m
CRI	≥80RA	≥80RA
O.T	-25℃ ~ 60℃	-25℃ ~ 60℃
