High Efficiency 2835 single color LED strip 64LEDs/M DC24V

Description

Use 2835 high brightness led, high purity gold line, SANAN chip.
64LEDs/M, single row LED, high luminance efficiency and high Ra.
Input voltage DC24V. Luminance efficiency
Flexible PCB, FPC color: white.
1+2 OZ copper thickness FPC, 10mm PCB width.
Standard length 5m per roll, the length also can be customized.

Share to

Specification

Product Parameter

PN	S010064BC1LZ (150lm)	Luminance efficiency
Voltage	DC24V	CCT	Ra80	Ra90
Power	5W/m	X Custom	☆ Standard
LED Type	SMD 2835	X2000K	105lm/w	95lm/w
LED Quantity	64LEDs/m	X2300K	120lm/w	105lm/w
Dimension	5000*10mm	X2500K	135lm/w	120lm/w
Cutting Length	125mm/8LEDs	X2700K	150lm/w	135lm/w
SDCM	<5, 3 step 1 bin	☆3000K	150lm/w	135lm/w
ErP 2019	D/E	X3500K	150lm/w	135lm/w
Beam Angle	120°	☆4000K	150lm/w	135lm/w
IP Rate	IP20/IP64/IP65/IP67	X5000K	150lm/w	135lm/w
O.T	-25℃ ~ 60℃	☆6500K	150lm/w	135lm/w

PN	S010064BC1LZ(180lm)	Luminance efficiency
Voltage	DC24V	CCT	Ra80	Ra90
Power	5W/m	X Custom	☆ Standard
LED Type	SMD 2835	X2000K	130lm/w	115lm/w
LED Quantity	64LEDs/m	X2300K	145lm/w	130lm/w
Dimension	5000*10mm	X2500K	160lm/w	145lm/w
Cutting Length	125mm / 8LEDs	X2700K	180lm/w	160lm/w
SDCM	<5, 3 step 1 bin	☆3000K	180lm/w	160lm/w
Power	5W/m	X3500K	180lm/w	160lm/w
Beam Angle	120°	☆4000K	180lm/w	160lm/w
IP Rate	IP20/IP64/IP65/IP67	X5000K	180lm/w	160lm/w
O.T	-25℃ ~ 60℃	☆6500K	180lm/w	160lm/w
