2 in 1 Dual color 3528 LED Tape Light 120LEDs/M DC12V

Description

High density CCT color Adjustable LED strip has 120pcs 2 in 1 3528 LEDs
FPC in white color with 8mm Width, 2 Ounce copper
Cut-able every 3LEDs & 25mm
All soldering Pads are very large, allowing you to easily cut and reconnect
DC12V constant voltage operation
Both ends have 3pin bare wires for powering
3M tape attached on backside of FPC
5 meters per reel, 3 different waterproof types IP64, IP65, IP68
Only standard color temperatures are available




Share to

Facebook Twitter g+

Specification

Product Parameter

    PN
    S008120AB2PZ
    Voltage
    DC12V
    LED Type
    SMD 3528
    LED Quantity     120LEDs/m
    CCT     2800-3200K/4000-4500K/6000-6500K /9000-13000K
    Dimension
    5000*8mm
    Lumens/m
    WW:610 W:660lm
    PCB Color     White
    Power
    19.2W/m
    CRI
    85RA
    O.T     -30℃ ~ 45℃



Dimension (unit:mm)

IP Rate
