Dual color 5050 LED Tape Light 60LEDs/M DC24V

Description

CCT color Adjustable LED strip with 60pcs of 5050 2 in 1 LED chips
FPC in white color with 10mm Width, 2 Ounce copper
Cut-able every 6LEDs & 100mm
All soldering Pads are very large, allowing you to easily cut and
reconnect?DC24V constant voltage operation
Both ends have 3pin bare wires for powering
3M tape attached on backside of FPC
5 meters per reel, 3 different waterproof types IP64, IP65, IP68
Only standard color temperatures are available



Share to

Facebook Twitter g+

Specification

Product Parameter

    PN
    S010060CC2PZ
    Voltage
    DC24V
    LED Type
    SMD 5050
    LED Quantity     60LEDs/m
    CCT

    WW: 2800-3200K + W:6000-6500K

    Dimension
    5000*10mm
    Lumens/m
    W:408lm/WW:382lm
    PCB Color     White
    Power
    9.6W/m
    CRI
    85RA
    O.T     -25℃ ~ 60℃



Dimension (unit:mm)

IP Rate
